Liberty LSG202M 2 HP Omnivore Grinder Pump
The Liberty LSG202M is a heavy-duty submersible **grinder pump** in the LSG200 Series, engineered to handle tough solids in residential or commercial sewage systems. It features Liberty’s advanced **V-Slice® cutter technology** to finely shred rags, sanitary products, wipes, and other debris, ensuring consistent performance under high load.
Key Features & Benefits
- 2 HP motor with oil-filled, thermally protected design.
- V-Slice® cutter assembly made of hardened 440 stainless steel, delivering aggressive, alternating cuts to manage challenging solids.
- 1-1/4" FNPT discharge — standard for pressure sewer / grinder applications.
- Uni-body cast iron housing & volute — rugged, corrosion-resistant build for long life.
- Internal capacitor start — no need for external capacitor in this version.
- Quick-disconnect power cord for field servicing.
- Upper and lower dual shaft seals — silicon carbide and Viton® double lip — to protect internal components.
- Back vanes, open volute & debris relief slots — helps reduce clogging and maintain flow.
- Thermal protection & class B insulation — safeguards motor under heavy use.
Specifications
| Model | LSG202M |
| Horsepower | 2 HP |
| Discharge | 1-1/4" FNPT |
| Cutting System | V-Slice® cutter (440 SS) |
| Capacitor Type | Internal (no external capacitor required) |
| Seal System | Dual upper & lower shaft seals (silicon carbide / Viton) |
| Pump Body / Housing | Uni-body cast iron / epoxy powder coat |
The Liberty LSG202M is ideal for pressure sewer, grinder ejector, or high-lift wastewater systems where reliable solids handling and compact footprint matter. It must be paired with a control panel and proper electrical protection. Always adhere to Liberty’s installation manual and local plumbing / electrical codes.
