The Story
Liberty LSG202A Omnivore: The 2 HP Automatic Grinder Pump
The Liberty Pumps LSG202A Omnivore Grinder Pump is the heavy-duty, automatic solution you need for demanding commercial and residential sewage applications. This powerful, 2 hp pump is equipped with Liberty's advanced V-Slice® Cutter Technology, featuring hardened 440 stainless steel blades that shred difficult solids into small particles prior to discharge under high pressure. Since the LSG202A features internal capacitors, it simplifies installation by eliminating the need for a separate control panel.
Designed for reliability, the pump is built with a one-piece cast iron uni-body with a powder coated finish. The automatic operation is managed by a wide-angle float switch with a piggyback plug. Other premium features include a 316 stainless steel impeller, a 300 series stainless steel rotor shaft, and dual seals for long-term protection. This 208/230V single-phase model comes with a 25? quick-connect power cord standard and is protected by a 3 year warranty.
Features:
- 2 hp, heavy-duty motor – oil filled, thermally protected
- Upper and lower ball bearings
- One-piece uni-body cast iron housing
- 300 Series SS Rotor Shaft
- 316 Stainless steel impeller
- Dual seals – Upper seal is unitized durable silicon carbide. Lower seal is Viton double-lip. (Lower seal ensures that all debris is kept away from main seal.)
- Motor windings insulated to Class B (130 ?C)
- Advanced V-Slice cutting system made of hardened 440 stainless steel - Rockwell C 58
- Horizontal 1-1/4" FNPT Discharge
- Back vanes on impeller and spiraled bottom plate for superior solids clearing
- All stainless steel fasteners
- Clog-free volute design
- Designed for maximum heat dissipation and cool motor operating temperatures
- Solid state starting circuit - no mechanical relay coil
- 25' power cord with Quick-Disconnect
- Piggy back plug with wide angle float (on automatic model) eliminates need for expensive panel
Specifications:
- HP: 2
- Volts: 208 - 230
- Phase: 1
- HZ: 60
- Amps: 15
- Locked Rotor Amps: 53
- Speed (RPM): 3450
- Dishcharge: 1-1/4"
- Switch: Yes
- Weight: 86
Description
Liberty LSG202A Omnivore: The 2 HP Automatic Grinder Pump
The Liberty Pumps LSG202A Omnivore Grinder Pump is the heavy-duty, automatic solution you need for demanding commercial and residential sewage applications. This powerful, 2 hp pump is equipped with Liberty's advanced V-Slice® Cutter Technology, featuring hardened 440 stainless steel blades that shred difficult solids into small particles prior to discharge under high pressure. Since the LSG202A features internal capacitors, it simplifies installation by eliminating the need for a separate control panel.
Designed for reliability, the pump is built with a one-piece cast iron uni-body with a powder coated finish. The automatic operation is managed by a wide-angle float switch with a piggyback plug. Other premium features include a 316 stainless steel impeller, a 300 series stainless steel rotor shaft, and dual seals for long-term protection. This 208/230V single-phase model comes with a 25? quick-connect power cord standard and is protected by a 3 year warranty.
Features:
- 2 hp, heavy-duty motor – oil filled, thermally protected
- Upper and lower ball bearings
- One-piece uni-body cast iron housing
- 300 Series SS Rotor Shaft
- 316 Stainless steel impeller
- Dual seals – Upper seal is unitized durable silicon carbide. Lower seal is Viton double-lip. (Lower seal ensures that all debris is kept away from main seal.)
- Motor windings insulated to Class B (130 ?C)
- Advanced V-Slice cutting system made of hardened 440 stainless steel - Rockwell C 58
- Horizontal 1-1/4" FNPT Discharge
- Back vanes on impeller and spiraled bottom plate for superior solids clearing
- All stainless steel fasteners
- Clog-free volute design
- Designed for maximum heat dissipation and cool motor operating temperatures
- Solid state starting circuit - no mechanical relay coil
- 25' power cord with Quick-Disconnect
- Piggy back plug with wide angle float (on automatic model) eliminates need for expensive panel
Specifications:
- HP: 2
- Volts: 208 - 230
- Phase: 1
- HZ: 60
- Amps: 15
- Locked Rotor Amps: 53
- Speed (RPM): 3450
- Dishcharge: 1-1/4"
- Switch: Yes
- Weight: 86
